PRODUCTS
Explore fittings, valves, tubing, quick couplings and flexible connections for instrumentation, hydraulic and industrial fluid systems.
Smooth bore PTFE hose assembly with a convoluted outer liner profile and 304/316 stainless steel braid for flexible fluid connections. The PTFE liner provides a smooth internal flow path, while the external convoluted profile improves flexibility for compact equipment and piping installations.
316L stainless steel annular corrugated metal hose assembly with 304/316 stainless steel braid for flexible industrial connections. Available with configurable end connections and custom assembly lengths to suit different piping and equipment interfaces.
The 87311 SAE Code 61 straight flange hydraulic hose fitting is designed for connecting braided hydraulic hose assemblies to SAE flange ports. Its straight configuration combines an SAE 3000 psi flange connection with a hose stem for crimped hose assembly.
Straight male NPT hydraulic hose fitting with a hose stem for hydraulic hose assemblies. Available in stainless steel and carbon steel for connection to compatible female NPT ports in hydraulic and industrial fluid systems.
ORFS female flat face swivel hydraulic hose fitting with a straight hose stem for hydraulic hose assemblies. Designed to mate with compatible ORFS male face-seal connections and available in stainless steel and carbon steel.
90° BSP female 60° cone swivel hydraulic hose fitting with a hose stem for hydraulic hose assemblies. Available in stainless steel and carbon steel for applications requiring angled hose routing and compatible BSP connections.
Metric heavy female 24° cone O-ring hydraulic hose fitting with a straight hose stem for hydraulic hose assemblies. Available in stainless steel and carbon steel for compatible metric heavy-series connections.
JIC female swivel hydraulic hose fitting with a 37° flare connection and straight hose stem for hydraulic hose assemblies. Available in stainless steel and carbon steel to suit different hydraulic system requirements.
Stainless steel 3-valve instrument manifold designed for isolation and equalization in differential-pressure measurement systems. The integrated manifold combines two isolation valves and one equalizing valve in a compact block configuration for connection between process lines and differential-pressure instruments.
Stainless steel 5-valve instrument manifold designed for isolation, equalization and venting in differential-pressure measurement systems. The integrated manifold combines two isolation valves, one equalizing valve and two vent valves in a compact block configuration for differential-pressure instrumentation.
Stainless steel screwed bonnet needle valve designed for manual flow isolation and regulation in high-pressure instrumentation and fluid-control systems. The straight-pattern valve is available with threaded or tube-fitting end connections, with maximum working pressure up to 6000 psig (414 bar) depending on the selected configuration.
316L stainless steel 2-valve block and bleed manifold designed for instrument isolation and controlled venting in high-pressure fluid systems. This configuration combines 1/2 in. Female NPT and Male NPT process connections with an independent 1/4 in. NPT bleed port, with maximum working pressure up to 6000 psig (414 bar).
PRODUCT MATCHING
Share your product requirements or existing part references for product matching and review. Drawings, BOMs and supporting files can be sent by email.
REQUIREMENT REVIEW
Provide the key product details below. For drawings, BOMs or supporting files, please send them by email.
